Brand:
Trumpf
Model:
PUNCHING MACHINE TRUMPF TRUPUNCH 5000 - 1600 (S12), FMC, SM-1354
Type:
turret punch press
Year of manufacture:
2021
Location:
Germany
Backnang6939 km to "United States/Columbus"
Backnang6939 km to "United States/Columbus"
Seller stock ID:
SM-1354
Placed on:
Oct 13, 2025
Condition
Condition:
used
Trumpf turret punch presses
Search results:
19 ads
Working area: 3050 x 1550 mm
Punching force: 22 to
Control: Siemens Sinumerik 840 D SL
Max. sheet thick: 8 mm
Max. material weight: 280 kg
CONFIGURATION
Standard configuration
Machine
C frame
Coordinate guide
Linear magazine with 25 stations for clamps and tools 4 clamps
Drives with maintenance-free three-phase motors
Repositioning device with programmable presser foot
Foot switch for closing clamps
Part chute
Part removal flap
ToolMaster Linear retrofitability
Punching head
Electro-hydraulic punching head
Rotary single station tool adapter
Manually adjustable presser foot force
Programmable presser foot position
Tool length compensation
Punch spray lubrication
Punching slug suction system with status monitoring
Forming function
Punch stroke counter
Tool lubrication level monitoring
On-Demand Drive
Stripper position measurement system with sheet thickness measuring function
Control
Open control based on Siemens 840D SL
Touch panel with TFT 19 color screen
Auto-shutdown
Remote support interface
Program manager
Data transmission
USB interface
RJ45 network interface
Central Link
Online Update Manager
Safety
CE marking
Double-beam safety light barrier
Quick shutdown of drives
Warped sheet detection
Advanced standard configuration
1st index pin (inside right)
Hydraulic clamps (4 x)
Ball tables
Finished part container
Chip container
Additional equipment
Advanced punching equipment
MultiTool function
MultiBend function
Tapping function with thread counter
Forming tap breakage control
Lubricant level monitoring
Markingquick beading function
Deburring and rolling technology function
Die spray lubrication with level monitoring
Active die
incl brush flap and marking from below
Integrated flattening function
Advanced machine equipment
Automatic closing of clamp
With mechanical zero stop sensor
Repositioning cylinder
Sensor for part chute
Vibration damping (installation on air cushions)
Chip conveyor with tilt container
Special thin sheet processing
Brush tables with loading and unloading aid
Blow-out device for small parts
Data transmission
Wireless Operation Point
Automation
SheetMaste
r
SheetMaster 3000 x 1500 mm (AS15)
Suction frame
Suction cups including peeler suction cups (35 operating circuits that can be
controlled individually)
Suction plate module including centering function (27 operating circuits that can
be controlled individually)
Vacuum sensor system
Double sheet detection
Optical loading sensor system
SheetMaster options
Loading station with fanning magnet
Unloading platform
Peeling system including positioning aid for large-sized sheets
GripMaster
GripMaster 3000 x 1500 mm
3 scrap skeleton grippers 1 of which with sensor system
Scissor table 400 mm
Tilting scrap skeleton pallet 3000 x 1500 mm
ToolMaster
ToolMaster Linear with 54 stations
FMC storage systems
Store interface
